1009C Murata Power Solutions Inc.
Favorite
Compare
Manufacturer:
Murata Power Solutions Inc.
MFR Product Number:
1009C
Product Number:
1009C
MFR Standard Lead Time:
Package/Case:
Detailed Description:
PULSE XFMR 1:1:1 22MH
Datasheet:
Descnt:
22mH General Purpose Pulse Transformer 1:1:1 Through Hole
In Stock
7000
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
Murata Power Solutions Inc.
Series
1000
Packaging
Tube
Part Status
Not For New Designs
Transformer Type
General Purpose
Inductance
22mH
ET (Volt-Time)
550VµS
Turns Ratio - Primary:Secondary
1:1:1
Mounting Type
Through Hole
Size / Dimension
0.593" L x 0.593" W (15.06mm x 15.06mm)
Height - Seated (Max)
0.640" (16.25mm)
Operating Temperature
0°C ~ 70°C
Base Product Number
100
-
Documents & Media
Datasheets
1000 Series Datasheet
Power Magnetics Selection Guide
-
Environmental & Export Classifications
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
Not Applicable
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8504.31.2000
-
Additional Resources
Standard Package
30
-
