126C Hammond Manufacturing
Favorite
Compare
Manufacturer:
Hammond Manufacturing
MFR Product Number:
126C
Product Number:
126C
MFR Standard Lead Time:
4 Weeks
Package/Case:
Detailed Description:
AUDIO XFMR 10K / 10K CHAS MNT
Datasheet:
Descnt:
10k Impedance Primary Ohms 10k Impedance Secondary Ohms Audio Transformer 20Hz ~ 20kHz Chassis Mount
In Stock
1
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
Hammond Manufacturing
Series
126
Packaging
Box
Part Status
Active
Turns Ratio - Primary:Secondary
-
Impedance - Primary (Ohms)
10k
Impedance - Secondary (Ohms)
10k
DC Resistance (DCR) - Primary
375Ohm
DC Resistance (DCR) - Secondary
375Ohm
Transformer Type
Single Ended Audiophile, Ultra-Linear - Tube Output
Frequency Range
20Hz ~ 20kHz
Frequency Response
±1dB
Voltage - Isolation
400VDC
Insertion Loss
-
Return Loss
-
Power Level
4W
Operating Temperature
-
Approval Agency
-
Mounting Type
Chassis Mount
Size / Dimension
3.120" L x 2.500" W (79.25mm x 63.50mm)
Height - Seated (Max)
3.120" (79.25mm)
Termination Style
Wire Leads
Weight
3.2 lbs (1.5 kg)
-
Documents & Media
Environmental & Export Classifications
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
Not Applicable
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8504.31.4065
-
Additional Resources
Other Names
Standard Package
1
