2ED2304S06FXUMA1 Infineon Technologies
Favorite
Compare
Manufacturer:
Infineon Technologies
MFR Product Number:
2ED2304S06FXUMA1
Product Number:
2ED2304S06FXUMA1
MFR Standard Lead Time:
16 Weeks
Package/Case:
8-SOIC (0.154\, 3.90mm Width)
Detailed Description:
IC GATE DRVR LEV SHIFT JUNCTION
Datasheet:
Descnt:
Half-Bridge Gate Driver IC CMOS PG-DSO-8-910
In Stock
7000
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
Infineon Technologies
Series
-
Packaging
Tape & Reel (TR)
Cut Tape (CT)
Customized-Package
Part Status
Active
DigiKey Programmable
Not Verified
Driven Configuration
Half-Bridge
Channel Type
Synchronous
Number of Drivers
2
Gate Type
IGBT, N-Channel MOSFET
Voltage - Supply
10V ~ 17.5V
Logic Voltage - VIL, VIH
1.1V, 1.7V
Current - Peak Output (Source, Sink)
360mA, 700mA
Input Type
CMOS
High Side Voltage - Max (Bootstrap)
650 V
Rise / Fall Time (Typ)
48ns, 24ns
Operating Temperature
-40°C ~ 125°C (TA)
Mounting Type
Surface Mount
Package / Case
8-SOIC (0.154", 3.90mm Width)
Supplier Device Package
PG-DSO-8-910
Base Product Number
2ED2304
Documents & Media
Environmental & Export Classifications
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
2 (1 Year)
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8542.39.0001
-
Additional Resources
Other Names
Standard Package
2,500
