56T300C Murata Power Solutions Inc.
Favorite
Compare
Manufacturer:
Murata Power Solutions Inc.
MFR Product Number:
56T300C
Product Number:
56T300C
MFR Standard Lead Time:
11 Weeks
Package/Case:
Detailed Description:
CURR SENSE XFMR 10A T/H
Datasheet:
Descnt:
10 A Current Sense Transformer 20kHz ~ 200kHz 5.73Ohm Primary, 8.59Ohm Secondary Through Hole
In Stock
14
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
Murata Power Solutions Inc.
Series
5600
Packaging
Box
Part Status
Active
Frequency Range
20kHz ~ 200kHz
Type
Non-Invasive (Solid Core)
Current Rating (Amps)
10 A
ET (Volt-Time)
-
Turns Ratio - Primary:Secondary
-
Current Ratio
300CT:1
DC Resistance (DCR)
5.73Ohm Primary, 8.59Ohm Secondary
Ratings
-
Mounting Type
Through Hole
Size / Dimension
0.661" L x 0.350" W (16.79mm x 8.89mm)
Height - Seated (Max)
0.795" (20.19mm)
Termination Style
PC Pin
Weight
0.013 lb (5.70 g)
Base Product Number
56T
Documents & Media
Environmental & Export Classifications
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
Not Applicable
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8504.31.4035
-
Additional Resources
Other Names
Standard Package
25
