ACST-261-1 Zettler Magnetics
Favorite
Compare
Manufacturer:
Zettler Magnetics
MFR Product Number:
ACST-261-1
Product Number:
ACST-261-1
MFR Standard Lead Time:
19 Weeks
Package/Case:
Detailed Description:
CURRENT SENSE TRANSFORMER
Datasheet:
Descnt:
30 A 1:1000 Current Sense Transformer 50Hz ~ 200Hz 0.6mOhm 2.4 H Through Hole
In Stock
304
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
Zettler Magnetics
Series
ACST-200
Packaging
Tray
Part Status
Active
Frequency Range
50Hz ~ 200Hz
Type
Invasive
Current Rating (Amps)
30 A
Inductance
2.4 H
ET (Volt-Time)
-
Turns Ratio - Primary:Secondary
1:1000
Current Ratio
1000:1
DC Resistance (DCR)
0.6mOhm
Ratings
-
Mounting Type
Through Hole
Size / Dimension
0.807" L x 0.690" W (20.50mm x 17.53mm)
Height - Seated (Max)
0.650" (16.51mm)
Termination Style
PC Pin
Weight
-
Documents & Media
Environmental & Export Classifications
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
Not Applicable
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8504.31.2000
-
Additional Resources
Other Names
3388-ACST-261-1
Standard Package
48
