ATMEGA169PA-MNR Microchip Technology
Favorite
Compare
Manufacturer:
Microchip Technology
MFR Product Number:
ATMEGA169PA-MNR
MFR Standard Lead Time:
10 Weeks
Package/Case:
64-VFQFN Exposed Pad
Detailed Description:
IC MCU 8BIT 16KB FLASH 64QFN
Datasheet:
Descnt:
AVR AVR® ATmega Microcontroller IC 8-Bit 16MHz 16KB (8K x 16) FLASH 64-QFN (9x9)
In Stock
Contact Name
Business Email
Company Name
Country
Select
Quantity
Quick RFQ
Product Attributes
Mfr
Microchip Technology
Series
AVR® ATmega
Packaging
Tape & Reel (TR)
Cut Tape (CT)
Customized-Package
Part Status
Active
DigiKey Programmable
Not Verified
Core Processor
AVR
Core Size
8-Bit
Speed
16MHz
Connectivity
SPI, UART/USART, USI
Peripherals
Brown-out Detect/Reset, LCD, POR, PWM, WDT
Number of I/O
54
Program Memory Size
16KB (8K x 16)
Program Memory Type
FLASH
EEPROM Size
512 x 8
RAM Size
1K x 8
Voltage - Supply (Vcc/Vdd)
1.8V ~ 5.5V
Data Converters
A/D 8x10b
Oscillator Type
Internal
Operating Temperature
-40°C ~ 105°C (TA)
Mounting Type
Surface Mount
Supplier Device Package
64-QFN (9x9)
Package / Case
64-VFQFN Exposed Pad
Base Product Number
ATMEGA169
-
Documents & Media
Datasheets
ATMEGA169A-6490P Summary
ATMEGA169A-6490P Datasheet
Product Training Modules
Studio Development Environment Overview Part 1
Advanced Software Framework (ASF) Example of Use
Studio Introduction to Software Framework (ASF)
Video File
Microchip Ethernet of Everything | Digi-Key Daily
Introducing Atmel Studio 7
Environmental Information
Microchip RoHS
Microchip REACH
Microchip CA Prop65
Featured Product
PIC and AVR MCUs
Atmel - megaAVR Microcontrollers
PCN Packaging
Transfer to Microchip/Label/Pkg 5/Sep/2016
MBB/Label Chgs 16/Nov/2018
Environmental & Export Classifications
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
3 (168 Hours)
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8542.31.0001
-
Additional Resources
Other Names
Standard Package
4,000
