AZ9741-1C-24D American Zettler
Favorite
Compare
Manufacturer:
American Zettler
MFR Product Number:
AZ9741-1C-24D
Product Number:
AZ9741-1C-24D
MFR Standard Lead Time:
9 Weeks
Package/Case:
Detailed Description:
RELAY AUTOMOTIVE SPDT 40A 24V
Datasheet:
Descnt:
In Stock
7000
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
American Zettler
Series
AZ9741
Packaging
Box
Part Status
Active
Coil Type
Non Latching
Coil Current
66.7 mA
Coil Voltage
24VDC
Contact Form
SPDT (1 Form C)
Contact Rating (Current)
40 A
Switching Voltage
75VDC - Max
Must Operate Voltage
15.6 VDC
Must Release Voltage
2.4 VDC
Operate Time
7 ms
Release Time
5 ms
Features
-
Mounting Type
Through Hole
Termination Style
PC Pin
Operating Temperature
-55°C ~ 125°C
Contact Material
Silver Tin Oxide (AgSnO)
Coil Power
1.6W
Coil Resistance
360 Ohms
-
Documents & Media
Environmental & Export Classifications
RoHS Status
ROHS3 Compliant
-
Additional Resources
Other Names
3385-AZ9741-1C-24D
Standard Package
100
