B82801C2245A200 EPCOS - TDK Electronics
Favorite
Compare
Manufacturer:
EPCOS - TDK Electronics
MFR Product Number:
B82801C2245A200
Product Number:
B82801C2245A200
MFR Standard Lead Time:
21 Weeks
Package/Case:
Detailed Description:
CURR SENSE XFMR 1:200 SMD
Datasheet:
Descnt:
1:200 Current Sense Transformer 50kHz ~ 500kHz 0.28mOhm Primary, 2.9Ohm Secondary 22.4 mH Surface Mount
In Stock
2503
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
EPCOS - TDK Electronics
Series
B82801C
Packaging
Tape & Reel (TR)
Cut Tape (CT)
Customized-Package
Part Status
Active
Frequency Range
50kHz ~ 500kHz
Type
Invasive
Inductance
22.4 mH
ET (Volt-Time)
-
Turns Ratio - Primary:Secondary
1:200
Current Ratio
-
DC Resistance (DCR)
0.28mOhm Primary, 2.9Ohm Secondary
Ratings
-
Mounting Type
Surface Mount
Size / Dimension
0.560" L x 0.530" W (14.22mm x 13.46mm)
Height - Seated (Max)
0.394" (10.00mm)
Termination Style
Gull Wing
Weight
0.011 lb (4.99 g)
-
