M224TAN 20.000000 MtronPTI
Favorite
Compare
Manufacturer:
MtronPTI
MFR Product Number:
M224TAN 20.000000
Product Number:
M224TAN-20-000000
MFR Standard Lead Time:
Package/Case:
4-SMD, No Lead
Detailed Description:
XTAL OSC XO 20.0000MHZ HCMOS TTL
Datasheet:
Descnt:
20 MHz XO (Standard) HCMOS, TTL Oscillator 3.3V Enable/Disable 4-SMD, No Lead
In Stock
100
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Mfr
MtronPTI
Series
M2
Packaging
Bulk
Part Status
Active
Base Resonator
Crystal
Type
XO (Standard)
Frequency
20 MHz
Function
Enable/Disable
Output
HCMOS, TTL
Voltage - Supply
3.3V
Frequency Stability
±50ppm
Absolute Pull Range (APR)
-
Operating Temperature
-40°C ~ 85°C
Spread Spectrum Bandwidth
-
Current - Supply (Max)
10mA
Ratings
-
Mounting Type
Surface Mount
Package / Case
4-SMD, No Lead
Size / Dimension
0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max)
0.075" (1.90mm)
Current - Supply (Disable) (Max)
-
-
Documents & Media
Environmental & Export Classifications
RoHS Status
RoHS Compliant
Moisture Sensitivity Level (MSL)
1 (Unlimited)
REACH Status
Vendor Undefined
ECCN
EAR99
HTSUS
8542.31.0000
-
Additional Resources
Other Names
3655-M224TAN20.000000
Standard Package
100
