MC705B16NCBE NXP USA Inc.
Favorite
Compare
Manufacturer:
NXP USA Inc.
MFR Product Number:
MC705B16NCBE
Product Number:
MC705B16NCBE
MFR Standard Lead Time:
Package/Case:
56-SDIP (0.600\, 15.24mm)
Detailed Description:
IC MCU 8BIT 15KB OTP 56PSDIP
Datasheet:
Descnt:
HC05 HC05 Microcontroller IC 8-Bit 2.1MHz 15KB (15K x 8) OTP 56-PSDIP
In Stock
7000
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Mfr
NXP USA Inc.
Series
HC05
Packaging
Tube
Part Status
Obsolete
DigiKey Programmable
Not Verified
Core Processor
HC05
Core Size
8-Bit
Speed
2.1MHz
Connectivity
SCI
Peripherals
POR, WDT
Number of I/O
32
Program Memory Size
15KB (15K x 8)
Program Memory Type
OTP
EEPROM Size
256 x 8
RAM Size
352 x 8
Voltage - Supply (Vcc/Vdd)
4.5V ~ 5.5V
Data Converters
A/D 8x8b
Oscillator Type
Internal
Operating Temperature
-40°C ~ 85°C (TA)
Mounting Type
Through Hole
Supplier Device Package
56-PSDIP
Package / Case
56-SDIP (0.600", 15.24mm)
Base Product Number
MC705
-
Documents & Media
Environmental & Export Classifications
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
3 (168 Hours)
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8542.31.0001
-
Additional Resources
Standard Package
9
-
