PCS020-EE05180S Bourns Inc.
Favorite
Compare
Manufacturer:
Bourns Inc.
MFR Product Number:
PCS020-EE05180S
Product Number:
PCS020-EE05180S
MFR Standard Lead Time:
20 Weeks
Package/Case:
Detailed Description:
CURRENT SENSE TRANSF 20A 180UH
Datasheet:
Descnt:
20 A 1:30 Current Sense Transformer 1MHz 7mOhm Primary, 870mOhm Secondary Max 180 mH Surface Mount
In Stock
7000
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
Bourns Inc.
Series
PCS
Packaging
Tape & Reel (TR)
Part Status
Active
Frequency Range
1MHz
Type
Invasive
Current Rating (Amps)
20 A
Inductance
180 mH
ET (Volt-Time)
16.2VµS
Turns Ratio - Primary:Secondary
1:30
Current Ratio
30:1
DC Resistance (DCR)
7mOhm Primary, 870mOhm Secondary Max
Ratings
-
Mounting Type
Surface Mount
Size / Dimension
0.245" L x 0.235" W (6.22mm x 5.97mm)
Height - Seated (Max)
0.209" (5.31mm)
Termination Style
Gull Wing
Weight
-
Documents & Media
Environmental & Export Classifications
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
1 (Unlimited)
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8504.31.2000
-
Additional Resources
Other Names
118-PCS020-EE05180STR
Standard Package
4,000
