PE-51686NL Pulse Electronics
Favorite
Compare
Manufacturer:
Pulse Electronics
MFR Product Number:
PE-51686NL
Product Number:
PE-51686NL
MFR Standard Lead Time:
20 Weeks
Package/Case:
Detailed Description:
CURR SENSE XFMR 20A T/H
Datasheet:
Descnt:
20 A Current Sense Transformer 20kHz ~ 200kHz 50Ohm Primary, 700mOhm Secondary 5 mH Through Hole
In Stock
1655
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
Pulse Electronics
Series
THT
Packaging
Tray
Part Status
Active
Frequency Range
20kHz ~ 200kHz
Type
Invasive
Current Rating (Amps)
20 A
Inductance
5 mH
ET (Volt-Time)
-
Turns Ratio - Primary:Secondary
-
Current Ratio
50:1
DC Resistance (DCR)
50Ohm Primary, 700mOhm Secondary
Ratings
-
Mounting Type
Through Hole
Size / Dimension
0.670" L x 0.390" W (17.01mm x 9.90mm)
Height - Seated (Max)
0.800" (20.32mm)
Termination Style
PC Pin
-
Documents & Media
Environmental & Export Classifications
RoHS Status
RoHS Compliant
Moisture Sensitivity Level (MSL)
1 (Unlimited)
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8504.31.2000
-
Additional Resources
Other Names
Standard Package
60
