PFSM.030.2 SCHURTER Inc.
Favorite
Compare
Manufacturer:
SCHURTER Inc.
MFR Product Number:
PFSM.030.2
Product Number:
PFSM-030-2
MFR Standard Lead Time:
22 Weeks
Package/Case:
2-SMD
Detailed Description:
PTC RESET FUSE 60V 300MA 2SMD
Datasheet:
Descnt:
Polymeric PTC Resettable Fuse 60V 300 mA Ih Surface Mount 2-SMD
In Stock
7000
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
SCHURTER Inc.
Series
PFSM
Packaging
Tape & Reel (TR)
Cut Tape (CT)
Customized-Package
Part Status
Active
Type
Polymeric
Voltage - Max
60V
Current - Hold (Ih) (Max)
300 mA
Current - Trip (It)
600 mA
Current - Max
40 A
Time to Trip
3 s
Resistance - Initial (Ri) (Min)
900 mOhms
Resistance - Post Trip (R1) (Max)
4.8 Ohms
Operating Temperature
-40°C ~ 85°C
Grade
Automotive
Qualification
AEC-Q200
Ratings
-
Mounting Type
Surface Mount
Package / Case
2-SMD
Size / Dimension
0.289" L x 0.214" W (7.36mm x 5.44mm)
Height - Seated (Max)
-
Thickness (Max)
0.125" (3.18mm)
Lead Spacing
-
Approval Agency
cURus, TUV
Base Product Number
PFSM.030
Documents & Media
Product Drawings
PSFM (030,050,075,100,125) 2 Side2
PFSM Series Footprint 2
PFSM (030,050,075) 2 Side 1
PFSM Series Footprint 1
-
Environmental & Export Classifications
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
Not Applicable
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8533.40.8070
-
Additional Resources
Other Names
Standard Package
2,000
