SG-615PTJ 30.0000MC0 EPSON
Favorite
Compare
Manufacturer:
EPSON
MFR Product Number:
SG-615PTJ 30.0000MC0
Product Number:
SG-615PTJ-30-0000MC0
MFR Standard Lead Time:
Package/Case:
4-SOJ, 5.08mm pitch
Detailed Description:
XTAL OSC XO 30.0000MHZ TTL SMD
Datasheet:
Descnt:
30 MHz XO (Standard) TTL Oscillator 5V Enable/Disable 4-SOJ, 5.08mm pitch
In Stock
7000
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Mfr
EPSON
Series
SG-615
Packaging
Tape & Reel (TR)
Part Status
Obsolete
Base Resonator
Crystal
Type
XO (Standard)
Frequency
30 MHz
Function
Enable/Disable
Output
TTL
Voltage - Supply
5V
Frequency Stability
±100ppm
Absolute Pull Range (APR)
-
Operating Temperature
-20°C ~ 70°C
Current - Supply (Max)
35mA
Ratings
-
Mounting Type
Surface Mount
Package / Case
4-SOJ, 5.08mm pitch
Size / Dimension
0.551" L x 0.341" W (14.00mm x 8.65mm)
Height - Seated (Max)
0.185" (4.70mm)
Current - Supply (Disable) (Max)
28mA
Documents & Media
HTML Datasheet
SG-615, 531, 51 Part Number Guide
SG-615, 531, 51 Series Datasheet
Product Drawings
SG615 Series Side 1
SG615 Series Footprint
SG615 Series Top
SG615 Series Side 2
Environmental & Export Classifications
RoHS Status
RoHS non-compliant
Moisture Sensitivity Level (MSL)
1 (Unlimited)
REACH Status
Vendor Undefined
ECCN
EAR99
HTSUS
8542.39.0001
-
Additional Resources
Other Names
Standard Package
1,000
