X-1569T iNRCORE, LLC
Favorite
Compare
Manufacturer:
iNRCORE, LLC
MFR Product Number:
X-1569T
Product Number:
X-1569T
MFR Standard Lead Time:
13 Weeks
Package/Case:
Detailed Description:
XFMR GATE DRIVE 1500VDC ISO
Datasheet:
Descnt:
3.3mH Gate Drive Pulse Transformer 1:1:1 Surface Mount
In Stock
1368
Contact Name
Business Email
Company Name
Country
Select
Tatget Price
Quantity
Quick RFQ
Application Guide:
Product Highlights:
Product Attributes
Manufacturer
iNRCORE, LLC
Series
-
Packaging
Tape & Reel (TR)
Cut Tape (CT)
Customized-Package
Part Status
Active
Transformer Type
Gate Drive
Inductance
3.3mH
ET (Volt-Time)
45.1VµS
Turns Ratio - Primary:Secondary
1:1:1
Mounting Type
Surface Mount
Size / Dimension
0.355" L x 0.340" W (9.01mm x 8.63mm)
Height - Seated (Max)
0.300" (7.62mm)
Operating Temperature
-40°C ~ 130°C
Weight
-
-
Documents & Media
Environmental & Export Classifications
RoHS Status
RoHS non-compliant
Moisture Sensitivity Level (MSL)
3 (168 Hours)
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8504.31.2000
California Prop 65
<img class="warning_image" src="//media.digikey.com/Icons/warning%20sign.jpg"/> Warning Information
Additional Resources
Other Names
Standard Package
400
